Product Features

ALL NEW DE39Y4!


3.32L Yanmar Engine
     Big power from a small package offers Tier 4 compliance
with superior exhaust emissions by improving the
combustion chamber and increasing the displacement
     and compression ratios.
Cummins Industrial Generator End
     With automatic voltage regulation.
Fork Pockets
     Convenient fork pockets integrated into the unit,
     giving you the ability to lift from all directions
WP DataTables

Additional Information

Standby Watts

120/240 1-PH: 30,000
120/208 3-PH: 30,000
120/240 3-PH: 30,000
277/480 3-PH: 30,000
346/600 3-PH: 30,000

Prime Watts

120/240 1-PH: 27,000
120/208 3-PH: 27,000
120/240 3-PH: 27,000
277/480 3-PH: 27,000
346/480 3-PH: 27,000

Standby Amps

120/240 1-PH: 125
120/208 3-PH: 104
120/240 3-PH: 90
277/480 3-PH: 45
346/600 3-PH: 36

Prime Amps

120/240 1-PH: 112
120/208 1-PH: 93
120/240 3-PH: 81
277/480 3-PH: 40
346/600 3-PH: 32

Voltage Output

120/208 Volt Three Phase, 120/240 Volt Single Phase, 120/240 Volt Three Phase, 277/480 Volt Three Phase, 346/600 Volt Three Phase

Voltage Regulation

AVR – AS540 +/- 1%

Engine

Brand: FPT
Model: F5C

Emissions

EPA Prime

Dimensions

71" x 29.9" x 46.8"

Weight

Without Tank: 2,020 lbs
With Tank: 2,230 lbs

Unit Warranty

1 year/2000 hours

Assembled In

USA
