Support for Model: W10000VE-03/A
| General Information | ||
| Spec Sheet | Operators Manual | Parts List |
| Load Balancing | Tri-Fold Brochure | |
| Drawings | ||
| Outline Drawing | ||
| Engine | ||
| Operators Manual | Parts List | Vanguard Winterization |
| Generator | ||
| Spec Sheet | Operators Manual | AVR Manual |
| Additional Information | ||
| Battery | Dolly Kit Installation Instructions |
Additional Information
| Starting Watts | 10000 |
|---|---|
| Running Watts | 9600 |
| Running Amps | 80/40 |
| Voltage Output | 120/240 Volt Single Phase |
| Voltage Regulation | AVR (Automatic Voltage Regulator) |
| 120V Receptacles | (2) NEMA 5-20R 20A (GFCI) |
| 120/240V Recpetacles | (1) NEMA 14-50R 50A (GFCI) |
| 240V Receptacles | (1) NEMA L6-30R 30A (GFCI) |
| Engine Brand | Briggs |
| Fuel | Gasoline |
| Emissions | CARB/California, EPA Prime |
| Dimensions | 34.3" x 24.6" x 23.4" |
| Weight | 298 lbs. |
| Unit Warranty | 3 Years Commercial |
| Assembled In | USA |
Share your thoughts!
Let us know what you think...
What others are saying
Related products
Call us crazy, but we just want you to get the right generator. We provide, where possible and applicable, our competitors’ model that is comparable with our own. We are unafraid of our pricing or our products. So if you can’t figure out why a competitor is beating us in price, please ask. We can usually provide a few reasons. If there isn’t a comparable product, we’ll use this space to tell you why.
Question
David Brevelle –
Why is this version now using the the Mecc Alte ES series instead of the brushless S series alternator on the older (WC10000VE). And why only switch to a brushed alternator on this model when the rest of your line is using brushless?
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Flag for removal
Dan Call –
Thanks for your question David. The old WC10000VE/E had no load voltage of about 247 VAC. At full load the voltage would be close to 220 VAC. Some of our customers wanted less voltage variation so we implemented 2 models using the ES versions. These generators are brush design because they have an AVR which allows the voltage to remain much more consistent than the capacitor controlled brushless designs.
Upvote if this was helpful (0) Downvote if this was not helpful (0) Flag for removal
