Additional Information
| Starting Watts | 22,000 |
|---|---|
| Running Watts | 19,000 |
| Running Amps | 158.3/79.2 |
| Voltage Output | 120/240 Volt Single Phase |
| Voltage Regulation | AVR (Automatic Voltage Regulator) |
| 120V Receptacles | (4) NEMA 5-20 20A (GFCI) |
| 120/240V Receptacles | (1) CS6369 50A |
| 120/240V Anderson Connector | 120 Amps |
| Engine Brand | Briggs |
| Fuel | Gasoline |
| Emissions | EPA Prime |
| Dimensions | 43" x 28.85" x 28.85" |
| Weight | 504 lbs. |
| Unit Warranty | 3 Year Commercial |
| Assembled In | USA |
Question
Glen Monceaux –
The ‘product features’ states that the generators comes with a full power Anderson plug kit included. What wire size will the plug kit accept? Or is it adaptable to varying wire sizes?
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Flag for removal
Dale Riebel –
Glen, the plug kit comes with 4 AWG contacts. If your application calls for larger wire size, larger contacts are available.
Upvote if this was helpful (0) Downvote if this was not helpful (0) Flag for removal
Glen Monceaux –
Thanks Dale. I was already planning to use 4 AWG for my application. So this will work perfect, thanks.
Upvote if this was helpful (0) Downvote if this was not helpful (0) Flag for removal
Question
Bill Valagura –
What Anderson connectors are available on this genset? Can it be ordered with Anderson PP120 or PP180 powerpole connectors installed by the manufacturer?
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Flag for removal
Dale Riebel –
Bill, this model comes with an Anderson Plug Kit that fits the full power Anderson receptacle. No other options are currently available for this model.
Upvote if this was helpful (0) Downvote if this was not helpful (0) Flag for removal
Bill Valagura –
What type of Anderson connectors come with the Anderson Plug Kit? Powerpole? Powerpole PAX? SB? SBE? SBX? Knowing what connector comes with the kit tells me what crimper I need to purchase when I build my genset power cord and what the largest size Type W cable I can use as well.
Upvote if this was helpful (0) Downvote if this was not helpful (0) Flag for removal
Dale Riebel –
Bill, the Anderson connector housing is a SB. The contacts that come in the plug kit are 4 AWG. Please consult the NEC (National Electric Code) table 400.5(A)(2) for the correct wire to use for your application. According to that table, 6 AWG 90 degree C copper wire, type W is rated for 87 amps. This would cover the amperage of circuit. You can order #6 AWG contacts seperatly from our Parts Department if needed.
Upvote if this was helpful (0) Downvote if this was not helpful (0) Flag for removal
Question
Nick –
Can the WL-22000VE-03C be fitted to accept natural gas or propane?
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Flag for removal
Question
Nick Nelson –
Can the WL-22000VE-03C be fitted to accept natural gas or propane?
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Flag for removal
Josie Krugerud –
Nick, please contact our Technical Support Department at 507-357-8334 or at [email protected].
Upvote if this was helpful (0) Downvote if this was not helpful (0) Flag for removal
What is the difference between the 03/C and the 03/A models of this
Mitchell M Brody –
I am looking for generator that will work electronics and won’t set my UBS alarms going
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Flag for removal
Question
Mitchell M Brody –
What is the difference between the 03/C and the 03/A models of this
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Flag for removal
