Question
Rosalie Williams –
where can I purchase the pigtail plug with the 3 round male legs that plug into the generator?
the one I had is gone
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Flag for removal
Dale Riebel –
Rosalie, please call our Parts Department at 507-357-8332 to order parts. FYI, the 3-wire plug is obsolete and replaced with the 4-wire plug. It will work and will plug into the original 3-wire receptacle. You will just have an extra contact in the plug kit that you will not use.
Upvote if this was helpful (0) Downvote if this was not helpful (0) Flag for removal
Question
Gregory Driscoll –
Have a 25PTOC-3E generator that is used sparingly when the power is out. Could be as long as a week at a time, though. The voltage vs the frequency is seemingly
rising at each use. To get it at 60Hz, it is requiring 126-128V. Is there a way to adjust this unit to bring the voltage closer to the standard 115-120V at 60Hz?
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Flag for removal
Dale Riebel –
Gregory, that is normal voltage for your model. The voltage will come down as you load the generator. Ideally you want 120 volts and 60 Hertz at half-load.
Upvote if this was helpful (0) Downvote if this was not helpful (0) Flag for removal
