Support for Model: HPS6000HE/I
| General Information | ||
| Spec Sheet | Operators Manual | Parts List |
| Tri-Fold Brochure | ||
| Drawings | ||
| Outline Drawing | ||
| Engine | ||
| Operators Manual | Shop Manual | EPA Certificate |
| Generator | ||
| Spec Sheet | Operators Manual | |
| Additional Information | ||
| Battery | Dolly Kit Installation Instructions |
Additional Information
| Starting Watts | 6000 |
|---|---|
| Running Watts | 5500 |
| Running Amps | 45/22.9 |
| Voltage Output | 120/240 Volt Single Phase |
| Voltage Regulation | Capacitor |
| 120V Receptacles | (1) NEMA 5-20 20A (GFCI) Duplex |
| 120/240V Recptacles | (1) NEMA L14-30 30A |
| Engine Brand | Honda |
| Emissions | EPA Prime |
| Dimensions | 32.75" x 22.5" x 22" |
| Weight | 224 lbs. |
| Unit Warranty | 2 Years Residential |
| Assembled In | USA |
Kenneth Gmerek –
Can this generator be connected directly to my natural gas line, via a quick disconnect. Also does this unit need a regulator or is there one on the unit it self. I’m replacing a whole house generator ( Briggs and Stratton) after it’s motors case cracked after ten years of ownership. Your input would be very helpful, Thank You
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Flag for removal
Dale Riebel –
Hi Kenneth. Please contact your gas supply company for local and state laws concerning a quick disconnect. Certain states have differing laws concerning those items and it is best to check first. There is no pressure regulator on the unit. Your pressure regulator is normally next to your house and provided by the gas company. Please call us if you have additional questions @ 507-357-6831.
Upvote if this was helpful (0) Downvote if this was not helpful (0) Flag for removal
